| KPLO MAGnetometer (KMAG) | ||
|---|---|---|
KMAG Flight Model (FM)
| KMAG Specifications | ||
|---|---|---|
| Magnetometer | Three-axis Fluxgate (racetrack) | |
| Size of FCE unit | 150 × 135 × 82 mm | |
| Size of MAG unit | 1,318 × 178 × 122 mm | |
| Mass | Total 3.5 kg | |
| Power Input | +28 V (unregulated +24 – 32.8 V) | |
| Power Consumption | 4.6 Watt | |
| Measurement range | 1,000 nT | |
| Resolution | < 0.2 nT at 10 Hz sampling rate | |
| Noise | < 50 pT / √Hz at 1 Hz | |
| Linearity | < 0.005 % | |
| Axis alignment | < 1 degree | |
| Magnetic cleanness | < 700 nT at the inner magnetometer (MAG 3) in the boom | |
| MAGs & LVPS Temperature: 2022.09.02 ~ 2024.10.07 | ||
|---|---|---|
